Product Description

1. Product Features

1. The body is made of high-quality steel plates and designed for high precision and high strength. After welding, it undergoes stress relief treatment, ensuring stable precision and reliable performance.
2. To ensure the relative stability of the machine operation, a pneumatic balancer device design is adopted.
3. The die adjustment precision reaches up to 0.1mm, ensuring safety, convenience, and reliability.
4. Components such as the crankshaft, gears, and screw undergo hard oxidation and grinding processes, providing excellent overall mechanical properties and wear resistance.
5. The machine structure is reasonably designed and well-equipped, facilitating automated production and assembly line production.
6. It features a high-performance combined clutch/brake system, ensuring smooth engagement and reliable safety.
7. Equipped with a safety double solenoid valve and hydraulic overload protection device, it maximizes operational safety during production.

2. Specification

Specification Unit SYA-25 SYA-35 SYA-45 SYA-60 SYA-80 SYA-110 SYA-130 SYA-160 SYA-160B SYA-200 SYA-200B SYA-260 SYA-260B SYA-315
Model V H V H V H V H V H V H V H V H V H V H V H V H V H V H
Capacity Ton 25 35 45 60 80 110 130 160 160 200 200 260 260 315
Rate tonnage point mm 3.2 1.6 3.2 1.6 3.2 1.6 4 2 4 2 6 3 6 3 6 3 6 3 6 3 6 3 7 3.5 6 3 8 4
Stroke mm 70 30 70 40 80 50 120 60 150 70 180 80 180 80 200 90 200 90 200 100 200 100 250 150 250 150 250 150
Speed changing s.p.m 60-140 130-200 40-120 110-180 40-100 110-150 35-90 80-120 35-80 80-120 30-60 60-90 30-60 60-90 20-50 40-70 20-50 40-70 20-50 50-70 20-50 50-70 20-40 40-50 20-40 40-50 20-40 30-50
Stable speed s.p.m 110 85 75 65 65 50 50 35 35 35 35 30 30 30
Die height mm 195 215 220 235 250 265 310 340 340 380 360 410 400 450 460 510 400 450 460 510 460 510 500 550 460 510 500 550
Slide adjustment mm 50 55 60 75 80 80 80 100 100 110 100 120 110 120
Slide area mm 470ｘ230ｘ50 520ｘ250ｘ50 560ｘ300ｘ60 700ｘ360ｘ70 770ｘ420ｘ70 910ｘ470ｘ80 910ｘ500ｘ80 990ｘ550ｘ90 990ｘ550ｘ90 1130ｘ630ｘ90 990ｘ550ｘ90 1250ｘ700ｘ100 1130ｘ630ｘ90 1250ｘ750ｘ100
Bolster area mm 680ｘ300ｘ70 800ｘ400ｘ70 850ｘ440ｘ80 900ｘ500ｘ80 1000ｘ550ｘ90 1150ｘ600ｘ110 1200ｘ600ｘ110 1250ｘ800ｘ140 1250ｘ760ｘ140 1400ｘ820ｘ160 1350ｘ820ｘ140 1500ｘ840ｘ180 1400ｘ820ｘ160 1600ｘ860ｘ190
Shank hole mm ∅38.1 ∅38.1 ∅38.1 ∅50 ∅50 ∅50 ∅50 ∅65 ∅65 ∅65 ∅65 ∅65 ∅65 ∅65
Main motor kw.p 3.7ｘ4 3.7ｘ4 5.5ｘ4 5.5ｘ4 7.5ｘ4 11ｘ4 11ｘ4 15ｘ4 15ｘ4 18.5ｘ4 18.5ｘ4 22ｘ4 22ｘ4 30ｘ4
Slide adjust device HP  manual operation electrial driving
Air pressure kg/cm2 6
Presses precision GB/JIS 1 class
Presses dimension mm 1350ｘ930ｘ2200 1400ｘ1050ｘ2400 1600ｘ1100ｘ2500 1620ｘ1150ｘ2800 1800ｘ1320ｘ3010 1920ｘ1450ｘ3200 1920ｘ1450ｘ3250 2460ｘ1550ｘ3610 2280ｘ1550ｘ3560 2640ｘ1850ｘ4080 2540ｘ1790ｘ3720 2820ｘ2000ｘ4450 2675ｘ1940ｘ4170 2820ｘ2010ｘ4500
Presses weight Ton 2.1 3 3.8 5.6 6.5 9.6 10 16 23 32 35
Die cushion capacity Ton - 2.3 2.3 3.6 3.6 6.3 6.3 10 10 14 14 14 14 14
Stroke mm - 50 50 70 70 80 80 80 80 100 100 100 100 100
Die cushion effective area mm2 - 300ｘ230 300ｘ230 350ｘ300 450ｘ310 500ｘ350 500ｘ350 650ｘ420 650ｘ420 710ｘ480 710ｘ480 710ｘ480 710ｘ480 710ｘ480
